Cisco ASR 1001 Hardware Installation Guide

DescriptionChapter and Appendix
This chapter describes the Cisco ASR 1002-X router and how to install it.
Chapter 10, “Cisco ASR 1002-X
Router Overview and
Installation"
This chapter describes the Cisco ASR 1013 router and how to install it.
Chapter 11, “Cisco ASR 1013
Router Overview and
Installation"
This chapter describes the Cisco ASR 1001 router and how to install it.
Chapter 12, “Cisco ASR 1001
Router Overview and
Installation"
This chapter provides basic system startup and initial configuration
information.
Chapter 13, “Cisco ASR 1000
Series Routers Power Up and
Initial Configuration"
This chapter provides instructions for removing and replacing shared port
adapters, ASR 1000 RP1 internal hard drive, AC and DC power supplies,
the Cisco ASR 1000 ESP forwarding processors, the Cisco DIMM memory
cards, the Cisco memory stick, and the Cisco ASR 1000 Series Route
Processors.
Chapter 14, “Removing and
Replacing FRUs from the Cisco
ASR 1000 Series Routers"
This appendix provides system specifications and pinouts.
Appendix A, “Cisco ASR 1000
Series Router Specifications"
This appendix lists pinout specifications for the Cisco ASR1000-RP1 and
the Cisco ASR1000-RP2.
Appendix B, “Cisco ASR 1000
Series Router Route Processor
and Embedded Services
Processor Signals and Pinouts"
This appendix provides basic system startup troubleshooting information.Appendix C, "Troubleshooting
Initial Startup Problems"
This appendix lists the MIBs that can be used to manage the Cisco ASR
1001 Router.
Appendix D, "MIBs for the
Cisco ASR 1001 Router"
The glossary lists Cisco ASR 1000 Series Routers terms with definitions.Glossary
Conventions
This document uses the following conventions:
IndicationConvention
Commands and keywords and user-entered text
appear in bold font.
bold font
Cisco ASR 1000 Series Router Hardware Installation Guide
xxv
Preface
Conventions

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
