Cisco ASR 1006 Router Console Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the front panel console port.
Table 100: Console Port Pinouts for Cisco ASR 1006 Router
DescriptionDirectionSignalPin
Request to Send (tied to
pin 8, CTS)
OutRTS1
Data Terminal Ready
(always On)
OutDTR2
Transmit DataOutTXD3
Ring Indicator
—
GND4
——
GND5
Receive DataInRXD6
Data Terminal ReadyInDSR7
Clear to Send (tied to pin
1, RTS)
InCTS8
Cisco ASR 1006 Router Auxiliary Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the auxiliary port signals.
Table 101: Auxiliary Port Pinouts for Cisco ASR 1006 Router
DescriptionDirectionSignalPin
Request to SendOutRTS1
Data Terminal Ready
(always On)
OutDTR2
Transmit DataOutTXD3
Ring Indicator
—
RI4
——
GND5
Cisco ASR 1000 Series Router Hardware Installation Guide
619
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1006 Router Console Port Signals and Pinouts

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
