Cisco ASR 1001 Hardware Installation Guide

SUMMARY STEPS
1.
Insert an Ethernet RJ-45 cable into the MGMT ETHERNET port.
2.
Insert the other end of the RJ-45 cable to your management device or network.
DETAILED STEPS
Step 1
Insert an Ethernet RJ-45 cable into the MGMT ETHERNET port.
Step 2
Insert the other end of the RJ-45 cable to your management device or network.
What to Do Next
A connection will not be established when setting up an out-of-band connection or modem connection in
the auxiliary port and the console port.
Note
Cisco ASR 1002-X Router Power Supplies
This section describes the Cisco ASR 1002-X Router power supplies and how to connect them:
Read the safety warnings before you begin.
The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed. Statement 1077
Warning
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
Never install an AC power module and a DC power module in the same chassis. Statement 1050Warning
Cisco ASR 1000 Series Router Hardware Installation Guide
351
Cisco ASR 1002-X Router Overview and Installation
Cisco ASR 1002-X Router Power Supplies

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
