DescriptionColorLEDLED Label
When the LED is off, it
signals that the –48 VDC
output voltage are within
the normal operating
range. Output voltage
between the minimum
and maximum limits will
not create an output fail
alarm, and output
voltages below the
minimum or above the
maximum will create an
Output Fail alarm.
When you turn the power
supply on, the red LED
illuminates for two to
three seconds to test LED
operation before going
off.
RedPower supply activityOUTPUT FAIL
AC/DC Power System Output for Cisco ASR 1006
The power supply output tolerance is defined in the following table under all combinations of line variation.
Total system consumption per power supply should not exceed 1200 W.
Table 19: Cisco ASR 1006 Router Power System Output Voltage and Current
+3.3 V+12 VDCOutput Voltage
3.20 VDC11.80 VDCMinimum
3.30 VDC12.00 VDCNominal
3.40 VDC12.20 VDCMaximum
Output Current
0.10 A2.80 AMinimum
3.125 A101.7 AMaximum
Cisco ASR 1000 Series Router Hardware Installation Guide
58
Cisco ASR 1000 Series Routers Component Overview
AC/DC Power System Output for Cisco ASR 1006

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
