Cisco ASR 1001 Hardware Installation Guide

Cisco ASR1000-RP2Cisco ASR1000-RP1
•
Up to 4 DIMMs with up to two DIMMs per
channel
•
DDR-533
•
Allowable memory options of 4 GB, 8 GB, or
16 GB
—
•
DDR-667
—
You might need to upgrade the DIMM for the following reasons:
•
You have upgraded to a new Cisco IOS feature set or release that requires more memory.
•
You are using very large routing tables or many protocols.
This section contains the following topics:
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006
Router and the Cisco ASR 1013 Router
The Cisco ASR 1006 Router and the Cisco ASR 1013 Router have redundant RPs. The following is an
overview of the steps to remove and replace the DIMM memory modules on these routers:
Cisco ASR 1000 Series Router Hardware Installation Guide
495
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006 Router and the Cisco ASR 1013 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
