Cisco ASR 1001 Hardware Installation Guide

SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
—
1745Minor Audible
Alarm
MINAA
—
18619Critical Visual
Alarm
CRTVA
—
2078Major Visual
Alarm
MAJVA
—
21922Minor Visual
Alarm
MINVA
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1001 Router Specifications
This section lists the specifications for the Cisco ASR 1001 Router. The following table lists the Cisco ASR
1001 Router physical specifications.
The Cisco ASR 1001 Router has the route processor, embedded services processor, and SIP integrated in
the chassis.
Note
Table 125: Cisco ASR 1001 Router Specifications
SpecificationDescription
Height: 1.71 in. (43.43 mm)
Width: 17.3 in. (439.42 mm)
Depth: 22.50 in. (571.5 mm) including card handles,
cable-management brackets, and power supply
handles)
Dimensions (H x W x D)
•
23.30 lb (10.6 kg) (with dual AC power and
integrated daughter card)
•
22.70 lb (10.3 kg) (with dual DC power and
integrated daughter card)
•
25 lb fully loaded
Weight
Cisco ASR 1000 Series Router Hardware Installation Guide
635
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1001 Router Specifications

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
