Cisco ASR 1001 Hardware Installation Guide

Do not run the AC power cord through the power supply handles as shown in Figure 165: Incorrect Cabling
on Cisco ASR 1002-X Router AC Power Supply , on page 354.
Caution
Figure 165: Incorrect Cabling on Cisco ASR 1002-X Router AC Power Supply
Using a tie wrap for the AC power cable is optional. However, if you do attach the AC power cable to a power
supply tab and then you remove the AC power cable for some reason, check for any damage to the cable after
you cut the tie wrap. If the power cord is damaged, replace it immediately.
Note
Step 4
Plug the AC power supply cable into the AC power source.
What to Do Next
This completes the procedure for connecting an AC power supply in the Cisco ASR 1002-X Router.
Connecting the –48 VDC Input Power to the Cisco ASR 1002-X Router
The –48 VDC power supply input connector is a Euro-style terminal block. A means to provide strain relief
to the input wires is provided on the power supply. The connection order is negative (–), positive (+), and
GND. However, this is the order from left to right in which the terminals appear on the power supply, not the
order in which the leads should be connected during installation. The order in which the leads should be
attached is GND, positive (+), and negative (-).
The recommended branch circuit breaker for the Cisco ASR 1002-X Router –48 VDC power supply is 30 A.
Use an AWG #10 wire gauge on the 30 A circuit.
Figure 166: –48 VDC Power Supply for the Cisco ASR 1002-X Router, on page 354 shows the –48 VDC
power supply for the Cisco ASR 1002-X Router.
Figure 166: – 48 VDC Power Supply for the Cisco ASR 1002-X Router
–48 VDC power supply
captive installation screw
6Chassis ESD socket1
–48 VDC power supply
slot 1 label
7
–48 VDC power supply
slot 0 label
2
Ground lead8
–48 VDC power supply
switch Standby/On
3
Positive lead9
–48 VDC power supply
LEDs
4
Negative lead10Fan5
Cisco ASR 1000 Series Router Hardware Installation Guide
354
Cisco ASR 1002-X Router Overview and Installation
Connecting the –48 VDC Input Power to the Cisco ASR 1002-X Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
