Cisco ASR 1001 Hardware Installation Guide

SUMMARY STEPS
1.
Make certain that the chassis ground is connected on the chassis before you begin installing the DC power
supply as shown in the xref “Attaching a Chassis Ground Connection” section.
2.
On the rear of the chassis next to the power supply bay PS1 as shown in the figure on page 5, make certain
the power supply switch is in Standby position.
3.
Turn off the circuit breaker to the power supply.
DETAILED STEPS
Step 1
Make certain that the chassis ground is connected on the chassis before you begin installing the DC power supply as
shown in the xref “Attaching a Chassis Ground Connection” section.
Step 2
On the rear of the chassis next to the power supply bay PS1 as shown in the figure on page 5, make certain the power
supply switch is in Standby position.
Step 3
Turn off the circuit breaker to the power supply.
Removing DC Input Power from the Cisco ASR 1001 Router
This section describes how to remove a DC power supply from the Cisco ASR 1001 Router. Follow these
steps:
SUMMARY STEPS
1.
Turn off the circuit breaker.
2.
On the rear of the chassis, place the Standby switch in the Standby position (|).
3.
Pull the terminal block plug connector out of the terminal block head in the power supply.
4.
Unscrew the two power supply fasteners on the unit.
5.
Grasping the power supply handle with one hand, pull the power supply out from the chassis, while at the
same time, supporting it with the other hand.
DETAILED STEPS
Step 1
Turn off the circuit breaker.
Step 2
On the rear of the chassis, place the Standby switch in the Standby position (|).
Step 3
Pull the terminal block plug connector out of the terminal block head in the power supply.
Step 4
Unscrew the two power supply fasteners on the unit.
Step 5
Grasping the power supply handle with one hand, pull the power supply out from the chassis, while at the same time,
supporting it with the other hand.
Cisco ASR 1000 Series Router Hardware Installation Guide
606
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing DC Input Power from the Cisco ASR 1001 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
