Cisco ASR 1001 Hardware Installation Guide

Power Supply Requirements for All Cisco ASR 1000 Series Routers
This section contains power supply specifications for all Cisco ASR 1000 Series Routers. The following topics
are covered:
•
DC power supply input ratings and circuit breaker specifications
◦
Maximum and minimum Amps for the branch circuit breakers
◦
Maximum and minimum size of the AWG wire required for each circuit breaker.
•
AC and DC power supply types
•
AC and DC power supply ratings
DC Power System Input Requirements for Cisco ASR 1000 Series Routers
The DC power supply for the Cisco ASR 1006, Cisco ASR 1004, Cisco ASR 100, Cisco ASR 1013, and Cisco
ASR 1001 routers operate at individual specifications.
The following table shows the common input ranges and circuit breaker requirements.
Table 14: Cisco ASR 1000 Series Router DC Power Supply System Input Requirements
AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
MaximumMinimumMaximumMinimum
Always AWG
#6 wire
Always 5040Cisco ASR 1006
810403024Cisco ASR 1004
Cisco ASR
1002:
• –48 VDC
•
+24 VDC
1012302016
88404032
Always AWG
#6 wire
Always 5040Cisco ASR 1013
1010302014Cisco ASR 1001
Cisco ASR 1000 Series Router Hardware Installation Guide
49
Cisco ASR 1000 Series Routers Component Overview
Power Supply Requirements for All Cisco ASR 1000 Series Routers

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
