Cisco ASR 1001 Hardware Installation Guide

DescriptionDirectionSignalPin
Data Set Ready/Data
Carrier Detect
InputDSR/DCD7
Clear to SendInputCTS8
Cisco ASR 1004 Router BITS Port Signals and Pinouts
The following table lists the pinouts of the front panel Building Integrated Timing Supply (BITS) RJ45 port.
Table 108: BITS RJ-45 Receptacle Pinouts for Cisco ASR 1004 Router
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive TIP (T1/E1)InputRX TIP2
——
N/C3, 4
—
UnusedTX Ring5
—
UnusedTX TIP6
——
N/C7,8
Cisco ASR 1004 Router DB-25 Pinout Assignments for Alarm Relays
The following table lists the common, normally open, and normally closed relay contacts accessible to an
external alarm monitoring facility by means of the DB-25 connector.
For more information about the DB-25 alarm connector, see Cisco ASR 1006 Router DB-25 Pinout Assignments
for Alarm Relays, on page 620.
Table 109: Cisco ASR 1004 Router DB-25 Alarm Connector Pinout Assignments
SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
—
1412Critical Audible
Alarm
CRTAA
—
15316Major Audible
Alarm
MAJAA
Cisco ASR 1000 Series Router Hardware Installation Guide
624
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router BITS Port Signals and Pinouts

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
