Cisco ASR 1001 Hardware Installation Guide

SUMMARY STEPS
1.
Carefully slide the hard drive unit into the slot on the front panel. The component is keyed for easy insertion.
2.
Tighten the fastener screw on the front panel by using a # 2 Phillips screwdriver or a flat head screwdriver.
3.
Wait until the following console message is displayed:
4.
Verify that the hard drive is working by running the following command:
DETAILED STEPS
Step 1
Carefully slide the hard drive unit into the slot on the front panel. The component is keyed for easy insertion.
Step 2
Tighten the fastener screw on the front panel by using a # 2 Phillips screwdriver or a flat head screwdriver.
Step 3
Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: file system ready” appears.
If this message is not displayed after a few minutes, run the following command:
request platform hardware filesystem harddisk: online
If the new hard drive system does not get mounted automatically, the disk may not be partitioned correctly.Note
Step 4
Verify that the hard drive is working by running the following command:
dir harddisk
What to Do Next
You have successfully replaced the hard drive on the Cisco ASR 1001 Router.
Removing and Replacing the Cisco ASR 1000 Series DIMM
Memory Modules
Cisco ASR 1000 Series Routers support the Cisco ASR1000-RP1 and the Cisco ASR1000-RP2 route processor
DIMM memory modules for system DRAM. This section describes how to replace the DIMMs on the Cisco
ASR1000-RP1, the Cisco ASR1000-RP2 route processors, the Cisco ASR 1001, and the Cisco ASR 1002-X
routers.
The following table shows the Cisco ASR1000-RP1 and Cisco ASR1000-RP2 memory design.
Table 89: Cisco ASR 1000 Series Route Processor Memory Support
Cisco ASR1000-RP2Cisco ASR1000-RP1
Supports up to 16 GB memorySupports up to 4 GB memory
•
4 GB dual rank VLP DIMMs
•
1 GB (2 GB) miniDIMMs
Cisco ASR 1000 Series Router Hardware Installation Guide
494
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR 1000 Series DIMM Memory Modules

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
