Cisco ASR 1001 Hardware Installation Guide

DescriptionPower Cord Item Number
10 A AC Power Cord, Left Angle (United Kingdom)
(bundle option)
CAB-AC10A-90L-UK
15 A AC Power Cord, Left Angle (United States)
(bundle option)
CAB-AC15A-90L-US
Plug, Power Cord, Australian, 10 A, Right AngleCAB-ACA-RA
Power Cord, Brazil, Right Angle, 10 ACAB-ACB10A-RA
Power Cord, Brazil, Right Angle, 16 ACAB-ACB16A-RA
Power Cord China, Right AngleCAB-ACC-RA
Power Cord Europe, Right AngleCAB-ACE-RA
Power Cord, Italian, Right AngleCAB-ACI-RA
Power Cord Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord UK, Right AngleCAB-ACU-RA
Power Cord-Japan, Right AngleCAB-JPN-RA
Connecting AC Input Power to Cisco ASR 1004 Router
Follow these steps to connect an AC input power supply to the Cisco 1004 chassis:
SUMMARY STEPS
1.
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
2.
Tighten the captive screws.
3.
Insert the AC power cable into the power inlet.
4.
Plug the power supply cable into the power source.
5.
Turn the power supply switch to the On position.
Cisco ASR 1000 Series Router Hardware Installation Guide
210
Cisco ASR 1004 Router Overview and Installation
Connecting AC Input Power to Cisco ASR 1004 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
