Page #367 background imageLoading...
Page #367 background image
The Cisco ASR 1002-X Router should be installed off the floor. Dust that accumulates on the floor is
drawn into the interior of the router by the cooling fans. Excessive dust inside the router can cause
overtemperature conditions and component failures.
There must be approximately 19 inches (48.3 cm) of clearance at the front and rear of the chassis to
install and replace FRUs, or to access network cables and equipment.
The Cisco ASR 1002-X Router needs adequate ventilation. Do not install it in an enclosed cabinet where
ventilation is inadequate.
Ensure that the cable management bracket is available if you plan to install it on the front of the chassis.
An adequate chassis ground (earth) connection exists for your router chassis. (See the Attaching a Chassis
Ground Connection, on page 346
When handling the chassis, always follow proper lifting practices as outlined in the Electrical Safety
section on page 5-21 .
Equipment Shelf or Tabletop Installation Procedure
To mount your Cisco ASR 1002-X Router on an equipment shelf or tabletop, follow these steps.
SUMMARY STEPS
1.
Remove debris and dust, if any, from the tabletop or platform, as well as from the surrounding area.
2.
Lift the chassis into position on the equipment shelf or tabletop (see following figure).
3.
Attach the front rack mount brackets. Locate the threaded holes in the front sides of the chassis (first holes
beyond the vent holes).
4.
Align the front rack mount bracket to one side of the chassis.
5.
Insert and tighten the black screws that shipped with the chassis on one side.
6.
Repeat Step-2 through Step-3 on the other side of the chassis. Use all the screws to secure the rack mount
brackets to the chassis.
7.
Gather the two cable management brackets and screws shipped with your chassis. Attaching the Cable
Management Bracket, on page 345 shows the cable management brackets attached on the front of the
Cisco ASR 1002-X Router.
8.
Screw the cable management bracket to each side of the rack mount brackets already attached to the
chassis. Use two screws for each cable management bracket. Use the packet of four screws.
9.
Verify if all the screws are securely tightened.
10.
Go to the Attaching a Chassis Ground Connection, on page 346 to continue the installation.
DETAILED STEPS
Step 1
Remove debris and dust, if any, from the tabletop or platform, as well as from the surrounding area.
Step 2
Lift the chassis into position on the equipment shelf or tabletop (see following figure).
Cisco ASR 1000 Series Router Hardware Installation Guide
333
Cisco ASR 1002-X Router Overview and Installation
Equipment Shelf or Tabletop Installation Procedure
