SpecificationDescription
Height: 22.8 in. (579.1 cm)
Width: 17.2 in. (437.4 cm)
Depth: 22 in (558.8 cm) with cable-management bracket and
power supply handles included
Dimensions (H x W x D)
•
184.0 lb (83.46 kg) (with redundant AC power supply, SPA
and route processor and SIP blank covers, two embedded
services processors, two route processors, six SIPs, and no
SPAs)
•
190.60 pounds (loaded with DC power supplies) (86.45 kg)
•
Total with estimated superslot weights with:
◦ AC power supplies—202 pounds (91.62 kg)
◦ DC power supplies —208.60 (94.61 kg)
Using the Cisco ASR1000-ESP100 instead of the Cisco
ASR1000-ESP40 adds 2.1 lbs to the total weight of the
router.
Note
Weight
5° to 40° CNominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum input (DC): 4,200W
• Maximum input (AC – High Line): 4,000 W
• Maximum output (DC and AC – High Line): 3,390 W
Power consumption (2x Zones)
•
Maximum input (DC): 2100W
• Maximum input (AC – High Line): 2,000WMaximum input
(AC – Low Line): 1,760W
• Maximum output (DC and AC – High Line): 1,695W
• Maximum output (AC – Low Line): 1,415W
Per Power Supply Power Consumption
Cisco ASR 1000 Series Router Hardware Installation Guide
631
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Specifications

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
