Cisco ASR 1001 Hardware Installation Guide

Security Traffic
Performance
BandwidthPerformanceMemoryEmbedded Services
Processor
40 Gbps200 Gbps
•
Quad
Quantum
Flow packet
processor
complex:
◦
2 GB
total
packet
buffer
◦
8 GB
total
resource
memory
•
Dual 80MB
TCAM4
feature lookup
memory
•
32GB of
1066MHz
DDR3
SDRAM:
◦
Four
8GB,
2-rank
registered
DIMMs
Cisco
ASR1000-ESP200
1
While both the Cisco ASR1000-ESP40 and ASR1000-ESP20 exceed the 16 Mpps forwarding rate, the ESP40 packets per second rate is slightly less than
ESP20 when sending continuous stream of small, 64-byte packets. However, at 92 bytes and larger, the ASR1000-ESP40 outperforms ESP20. The difference
at small packet sizes is a side-effect of optimizations made to achieve 40 Gbps for medium to large packets.
For unsupported hardware component configuration combinations, see xref Table 2-4.Note
The embedded services processor consists of a front panel label for indicator and control functions. The Cisco
ASR 1000 Series Embedded Services Processor model number labeling is located next to the left card module
handle. The module also contains card handles to assist in insertion or removal of the module. There are no
front panel interfaces on the Cisco ASR1000-ESP modules.
The following figure displays the Cisco ASR 1000 Series Embedded Services Processor LEDS on the front
panel.
Cisco ASR 1000 Series Router Hardware Installation Guide
97
Cisco ASR 1000 Series Routers Embedded Services Processors
Features of the Cisco ASR 1000 Series Embedded Services Processors

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
