Cisco ASR 1001 Hardware Installation Guide

Behavior DescriptionColorLEDLED Label
System failure or
powering up.
Red
The ACTV LED indicates
(in a redundant system)
the embedded services
processor board that is
actively forwarding
packets.
On the active embedded
services processor board,
the ACTV LED is green
and the STBY LED is off.
On the standby embedded
services processor board,
the STBY LED is yellow
and the ACTV LED is
off.
On Cisco ASR 1002
Router, Cisco ASR 1004
Router, and Cisco ASR
1002-F Router, the
embedded services
processor board is always
active because these
routers do not support
redundancy. The Cisco
ASR1000-ESP5 does not
support redundancy.
Therefore, it is always
active.
GreenActiveACTV
On a redundant system,
the STBY LED indicates
which embedded services
processor is in the
standby state and is
waiting to take over
packet forwarding in the
event that the active
embedded services
processor experiences a
failure. The STBY LED
is in the off state while
the active embedded
services processor is in
the on state.
YellowStandbySTBY
Cisco ASR 1000 Series Router Hardware Installation Guide
99
Cisco ASR 1000 Series Routers Embedded Services Processors
Features of the Cisco ASR 1000 Series Embedded Services Processors

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
