Cisco ASR 1001 Hardware Installation Guide

Saving the Running Configuration to NVRAM 470
Powering Off the Cisco ASR 1000 Series Router Safely 470
CHAPTER 14 Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers 473
Removing and Replacing Cisco ASR 1000 Series Route Processors 474
Removing the Cisco ASR 1000 Series Route Processor from the Cisco ASR 1006, Cisco ASR
1004, and Cisco ASR 1013 Routers 474
Replacing the Cisco ASR 1000 Series Route Processor in the Cisco ASR 1006, Cisco ASR
1004, and Cisco ASR 1013 Routers 475
Removing and Replacing Cisco ASR 1000 Series Route Processor Internal Hard Drive 476
Cisco ASR1000-RP1 Spare Hard Drive Accessory Kit 476
Removing and Replacing the Cisco ASR1000-RP1 Module Internal Hard Drive 477
Removing the Cisco ASR1000-RP1 Internal Hard Drive 477
Replacing the Cisco ASR1000-RP1 Internal Hard Drive 482
Removing and Replacing the Cisco ASR1000-RP2 Module Internal Hard Drive 484
Removing the Cisco ASR1000-RP2 Internal Hard Drive 484
Replacing the Cisco ASR1000-RP2 Internal Hard Drive 486
Removing and Replacing the Hard Drive on the Cisco ASR 1002-X Router 487
Removing the Hard Drive from the Cisco ASR 1002-X Router 488
Replacing the Hard Drive on the Cisco ASR 1002-X Router 490
Removing and Replacing the Hard Drive on the Cisco ASR 1001 Router 491
Removing the Hard Drive from the Cisco ASR 1001 Router 492
Replacing the Hard Drive on the Cisco ASR 1001 Router 493
Removing and Replacing the Cisco ASR 1000 Series DIMM Memory Modules 494
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006 Router and the
Cisco ASR 1013 Router 495
Removing and Replacing the Cisco ASR1000-RP1 DIMM Memory Modules 497
Removing and Replacing the Cisco ASR1000-RP2 DIMM Memory Modules 501
Removing the Cisco ASR1000-RP2 DIMMs 503
Replacing the Cisco ASR1000-RP2 DIMMs 504
Removing and Replacing the Cisco ASR 1001 Router DIMM Memory Modules 507
Removing the Cisco ASR 1001 Router DIMMs 508
Replacing the Cisco ASR 1001 Router DIMM 511
Removing and Replacing the Cisco ASR 1002-X Router DIMM Memory Modules 514
Removing the Cisco ASR1002-X Router DIMMs 515
Cisco ASR 1000 Series Router Hardware Installation Guide
xv
Contents

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
