Cisco ASR 1001 Hardware Installation Guide

The following image shows the rear of the Cisco ASR 1004 Router with two –48 VDC power supplies installed.
Figure 60: Cisco ASR 1004 Router Rear View With – 48 VDC Power Supplies
Grounding symbol5
–48 VDC power supply
terminal block
1
–48 VDC power supply
On/Off switch
6
–48 VDC power supply
LEDs
2
–48 VDC power supply
handle
7
–48 VDC power supply
DB-25 alarm connector
3
——–48 VDC power supply
fan
4
Internal fans draw cooling air into the chassis and across internal components to maintain an acceptable
operating temperature. (See Figure 59: Cisco ASR 1004 Router Rear View with AC Power Supplies, on page
183.) The fans are located at the rear of the chassis. A two-hole grounding lug is located on the side of the
chassis. Two power supplies, either two AC power supplies or two –48 VDC power supplies, are accessed
from the rear of the router.
You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
Note
Do not combine AC and –48 VDC power supplies in the same chassis.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
184
Cisco ASR 1004 Router Overview and Installation
Rear View

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
