Cisco ASR 1001 Hardware Installation Guide

Change SummaryDate
Added information about:
•
IDC-HD80G, IDC-4XGE, and IDC-CHT1/E1
integrated daughter cards on the Cisco ASR
1001 Router—See the Cisco ASR 1001 Router
Description, on page 407 for detailed
information.
• MIBs for the new IDCs—See the MIBs for the
Cisco ASR 1001 Router, on page 661 appendix
for the list of MIBs.
•
Cisco ASR 1013 Router power supplies on the
Cisco ASR 1006 Router—Information about
this new feature has been added in various
sections in this guide.
March 2011
Added information about:
•
New Cisco ASR 1001 Router at Cisco ASR
1001 Router Description, on page 407
•
Cisco ASR1000-SIP40 and Cisco
ASR1000-ESP40 products on the Cisco ASR
1004 Router
November 2010
Added information about Cisco ASR 1000 Series
Routers 40G products:
•
Cisco ASR 1013 Router Overview and
Installation
•
Cisco ASR 1000-ESP40, on page 89
•
Supported ASR 1000 Hardware Components,
on page 27
July 2010
Added information about the Cisco +24 VDC power
supply in the Cisco ASR 1002 Router. See the
following sections:
•
Cisco ASR 1002 Router +24 VDC Power
Supply, on page 71
•
Removing and Replacing the Cisco ASR 1002
Router Power Supplies, on page 565
•
November 2009
Cisco ASR 1000 Series Router Hardware Installation Guide
xxii
Preface
Document Revision History

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
