Cisco ASR 1001 Hardware Installation Guide

Table 71: Cisco ASR 1002-X Router – 48 VDC Power Supply LEDs
DescriptionColorLEDLED Label
The LED turns green to signal
that the DC power supply input
voltage is greater than 43.5VDC
at turn-on and remains green
until the level of 39 VDC is
reached.
GreenA bi-color LED indicates the
presence of input voltage
INPUT OK
The LED turns amber if the
power supply turns off due to
low input voltage (falls below
39VDC) and indicates that a
hazard (voltage on the terminal
block) is still present. The LED
remains amber and is active
until around 20 V +/-5 V. If the
input is below 15 V, the LED is
not illuminated
Amber
The LED turns green when all
fans are operational.
GreenA bi-color LED indicates power
supply fan status
FAN OK
The LED turns red when a fan
failure is detected.
Red
When the LED is off, it signals
that the DC output voltage is
within the normal operating
range. Output voltage between
the minimum limit and
maximum limit will not create
an Output Fail alarm, but output
voltages below the minimum
limit or above the maximum
limit will create an Output Fail
alarm.
Led turns red to indicate that the
DC output is out of the
specified range.
When you turn on the power
supply, the LED turns red for
two to three seconds to test the
LED operation before going off.
RedPower supply activityOUTPUT FAIL
Cisco ASR 1000 Series Router Hardware Installation Guide
326
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
