Cisco ASR 1001 Hardware Installation Guide

•
Online insertion and removal (OIR) capability
•
Route processor and embedded services processor redundancy in the Cisco ASR 1000 Series Routers
(Cisco ASR 1013 Router and Cisco ASR 1006 Router)
•
Control processor for ASR 1000 Series SPA Interface Processor
•
Control processor for embedded services processors (Cisco ASR1000-ESP5, Cisco ASR1000-ESP10,
Cisco ASR1000-ESP20, integrated Cisco ASR1002-ESP-F, Cisco ASR1000-ESP40, Cisco
ASR1000-ESP100, and Cisco ASR1000-ESP200)
•
10 Gbps and 20 Gbps interconnect between Cisco QuantumFlow Processor with redundant Cisco ASR
1000 Series ESP to mirror data for stateful features
•
Power supply redundancy
•
Environmental monitoring and reporting functions
•
Family of routers using common hardware and software architecture
•
Centralized forwarding design (all network traffic passes through one engine)
• Front-to-back airflow—Allows you to mount the router from either front or back into 19-inch equipment
rack
•
Supports half-height shared port adapters (HHSPAs) and full-height shared port adapters (FHSPAs)
The Cisco ASR 1001 Router does not support full-height SPAs.Note
•
Single midplane design (all connectors on one interface midplane)
• One 10/100/1000-Mbps Ethernet Management port—To be used only as a management port; not to be
used as an Ethernet interface port
•
Both quarter-rate (87.5 MHz) and full-rate (350 MHz) shared port adapter operation
The Cisco QuantumFlow Processor processing provides:
•
Architecture to address Cisco ASR 1000 Series router performance, cost, power, and feature velocity
•
Next Generation forwarding and queuing subsystems for Cisco routers to provide data path acceleration.
The Cisco ASR 1000 Series route processor system performs the following system management functions:
•
Sending and receiving routing protocol updates
•
Managing tables, caches, and buffers
•
Monitoring interface and environmental status
•
Providing Simple Network Management Protocol (SNMP) management through the console and Telnet
interface
•
Accounting for and switching of data traffic
•
Booting and reloading images
Cisco ASR 1000 Series Router Hardware Installation Guide
4
Cisco ASR 1000 Series Routers Hardware Overview
Cisco ASR 1000 Series Router Features

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
