Cisco ASR 1001 Hardware Installation Guide

There is no cover on the Cisco ASR 1002 Router and the Cisco ASR 1002-X Router DC power supply
terminal block; therefore, Statement 1029 does not apply to the Cisco ASR 1002 router.
Note
You are now ready to power on the system for the first time. Follow these steps.
SUMMARY STEPS
1.
Before you power on, make sure that:
2.
Move the power switch to the ON position. Listen for the fans; you should immediately hear them operating.
3.
Depending on your installation, some LEDs on the rear of the chassis and on installed modules also come
on.
4.
Observe the initialization process. When the system boot is complete (the process takes a few seconds),
the Cisco ASR 1000 RP1 begins to initialize.
5.
During the boot process, observe the system LEDs. The LEDs on the shared port adapter go on and off
in irregular sequence. They may go on, go out, and go on again for a short time. On the router, the green
STATUS LED comes on and stays on.
DETAILED STEPS
Step 1
Before you power on, make sure that:
a) The AC cord is plugged into the AC power inlet.
b) All cables are connected.
c) Your computer is powered up and connected.
To view the boot sequence, you must have a console connection to the Cisco ASR 1000 Series Routers
before it powers up.
Note
Step 2
Move the power switch to the ON position. Listen for the fans; you should immediately hear them operating.
Step 3
Depending on your installation, some LEDs on the rear of the chassis and on installed modules also come on.
Do not press any keys on the keyboard until the messages stop and the SYS PWR LED is solid green. Any
keys pressed during this time are interpreted as the first command typed when the messages stop, which might
cause the router to power off and start over. It takes a few minutes for the messages to stop.
Caution
This is only an example of what can display. The system boots differently depending upon the configuration
that ships with your system.
Note
Step 4
Observe the initialization process. When the system boot is complete (the process takes a few seconds), the Cisco ASR
1000 RP1 begins to initialize.
Example:
Loading the Default System Boot Image
rommon 1 >
rommon 1 > boot
Located rp_super.ppc.nader.5g.evfc.bin
Image size 211681484 inode num 12, bks cnt 51681 blk size 8*512
#######################################################################################
#############################################
Boot image size = 211681484 (0xc9e00cc) bytes
Using midplane macaddr
Package header rev 0 structure detected
Calculating SHA-1 hash...done
validate_package: SHA-1 hash:
calculated 479a7d62:6c128ba8:3616b8da:93cb3224:5c1aeb34
Cisco ASR 1000 Series Router Hardware Installation Guide
464
Cisco ASR 1000 Series Routers Power Up and Initial Configuration
Powering Up the Cisco ASR 1000 Series Routers

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
