Cisco ASR 1001 Hardware Installation Guide

Radio Frequency Interference 127
Lightning and AC Power Fault Interference 127
Rack-Mounting Guidelines 127
Precautions for Rack-Mounting 127
General Rack Selection Guidelines 128
Guidelines for 23 in. (Telco) Racks 128
Equipment Rack Guidelines 129
Locating for Safety 129
Locating for Easy Maintenance 129
Locating for Proper Airflow 130
Site Planning Checklist 130
Preventing Electrostatic Discharge Damage 130
Electrical Safety 131
Receiving the Cisco ASR 1000 Series Router 132
Chassis-Lifting Guidelines 133
Tools and Equipment 134
Unpacking and Verifying Shipping Contents 134
Checking the Shipping Container Contents 135
Cisco ASR 1000 Series Router Installation Checklist 136
CHAPTER 6 Cisco ASR 1006 Router Overview and Installation 139
Cisco ASR 1006 Router Description 139
Front View 140
Rear View 141
Cisco ASR 1006 Router Slot Numbering 142
Installation Methods 143
General Rack Installation Guidelines 143
Guidelines for an Equipment Shelf or Tabletop Installation 145
Equipment Shelf or Tabletop Installation 146
Rack-Mounting the Cisco ASR 1006 Router 148
Verifying Rack Dimensions 148
Attaching the Chassis Rack-Mount Brackets 149
Chassis Front Rack-Mount Brackets 149
Chassis Rear Rack-Mount Brackets 151
Installing the Cisco ASR 1006 Router in a Rack 153
Cisco ASR 1000 Series Router Hardware Installation Guide
vii
Contents

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
