Cisco ASR 1001 Hardware Installation Guide

Table 11: Cisco ASR 1000 Series Route Processor Connectors
DescriptionTypeLabel
A recessed button to cut off the
audible alarm. This is triggered
when the critical, major, or minor
LED is set.
Audible Cutoff buttonACO
Side-by-side USB connector used
with memory sticks or smart cards
for secure key distribution
USB0 interface0
Side-by-side USB connector used
with memory sticks or smart cards
for secure key distribution
USB1 interface1
Indicates BITS timing reference.RJ-45 connectorBITS
The route processor has an ENET
port with a RJ-45 connector to
attach a management device or
network for network management.
One RJ-45 jack for copper Ethernet
Management Port
MGMT ETHERNET
Console port used to connect to a
terminal.
One RJ-45 for CON/AUXCON
Auxiliary port used for remote
management purposes.
One RJ-45 for CON/AUXAUX
Out of Band (OOB) or modem connection in the AUX and/or CON ports, regardless of being properly
configured, the connection is not established and a call cannot be setup. This functionality is not supported
on any of the Cisco ASR 1000 Series Aggregation Services Routers or on any of the Cisco IOS XE
versions.
Note
The Cisco ASR 1000 Series Route Processor meets the following requirements:
•
Supports up to 4 GB of memory with single-bit error correction and multi-bit error detection (except
for the Cisco ASR 1002 embedded route processor)
•
Supports On-board Failure Logging (OBFL) with 2MB of memory
•
Supports the Cisco ASR 1000 Series Router system architecture and midplane
•
Enhanced Serdes Interconnect (ESI) at 11.5 Gbps.
•
Gigibit Ethernet switches for EOBC communication and boot-up of the Cisco ASR 1000 Series SPA
Interface (SIP) and Cisco ASR 1000 Series Embedded Services Processor.
•
Runs Cisco IOS network control plane (routing protocol, connections setup)
Cisco ASR 1000 Series Router Hardware Installation Guide
42
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1000 Series Route Processor Differences

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
