Cisco ASR 1001 Hardware Installation Guide

Behavior Description
Color —State
LEDLED Label
System failure or
powering up.
Red
Minor alarm indicator.AmberMinorMIN
Major alarm indicator.RedMajorMAJ
Critical alarm indicator.RedCriticalCRIT
Activity indicator.Flashing GreeneUSB0 FLASH(BootDiskBOOT
No activity.Off
Out of service or not
configured.
OffCARRIER
In frame and working
properly.
Green
Fault or loop condition.Amber
Link with no activity.Green10/100 /1000 RJ-45
Interface LED
LINK
Link with activity.Flashing Green
No link.Off
Port is not enabled.OffBuilt-in SPA SFP port
status
4 LEDs
Port enabled but there is
a problem with the
Ethernet link.
Amber
Port enabled, valid
Ethernet link
Green
All carrier card
requirements are within
specification.
GreenCarrier card powerPWR
Cisco ASR 1000 Series Router Hardware Installation Guide
45
Cisco ASR 1000 Series Routers Component Overview
Cisco Integrated ASR1000-RP1 for Cisco ASR 1002 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
