CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–50
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
Equipment ID
N/A
33 bytes
Query only.
Returns the equipment ID and installed options in the form AAAABCDEFGHsJKLMNPQRSTUVWXYZabcds, where:
AAAA=A625, the modem model number
Installed hardware:
B=Slot 1: TPC/LDPC codec, where:
0=not present
1=present
C=0 (Reserved for Expansion board)
D=VersaFEC-2 board, where:
0=not present
1=present
E=Slot 4: Network Processor card, where:
0=not present
1=present
F=spare (0)
G=External 20dB attenuator, where:
0=not present
1=present
H=Audio chips, where:
0=not present
1=present
s=spares (0)
Firmware FAST options:
J=Frequency option, where:
0=70/140MHz
1=70/140MHz & L-Band
K=Modulation option, where:
0=Standard: BPSK, QPSK, OQPSK.
1=Standard plus 8-ARY
3=Standard plus 8-ARY and 16-ARY
7=Standard plus 8-ARY, 16-ARY and 32-ARY
L=Data Rate option
M=TPC/LDPC data rate option
For L and M, the value is decoded:
0=Base, up to 5Mbps
1=up to 10Mbps
2=up to 15 Mbps
3=up to 20Mbps
4=up to 25Mbps
N=CnC data rate option, where:
0=No CnC FAST installed
1=up to 512kbps
2=up to 1.1Mbps
3=up to 2.5 Mbps
4=up to 5 Mbps
5=up to 10 Mbps
6=up to 15 Mbps
N/A
EID?
EID=AAAABCDEFGHs
JKLMNPQRSTUVWXY
Zabcds
(see Description of
Arguments)
