CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–54
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
Offline Unit Status
N/A
8 bytes
Query only. (1:1 set-up)
This query is sent to the online modem of a 1:1 pair. It provides access to the fault status information (FLT?) of the offline
modem. This is the only way to interrogate the status of an offline modem at the distant-end of a link. The response
format may be:
No_1for1=Indicates that no 1:1 system has been detected. Presence of a 1kHz signal from the CRS-150 is used to
indicate a 1:1 set-up;
No_Comms=Indicates that a 1kHz signal has been detected, but that there is no (or not yet) a response for the
modem;
abcdef=The FLT? response information from the offline 600L unit; or
abcdefghxx=The FLT? response information from the offline CDM-625A unit.
N/A
OUS?
OUS=xxxxxx
(see Description of
Arguments)
Faults and
Status
N/A
10 bytes
Query only.
Returns the current highest-priority fault and status codes for the Unit (hardware), TX Traffic, RX Traffic, and ODUs:
a=Unit status:
0=No faults
1=Power supply fault, +5 volts
2=Power supply fault , +12 volts
3=Power supply fault, -5 volts
4=Power supply fault, +3.3 volts
5=Power supply fault, -12 volts
6=Power supply fault, +2.5 volts
7=Top Card comms
8=Tx synthesizer lock
9=Rx synthesizer
A=Top card load fail
B=TPC/LDPC FPGA load fail
C=HDLC FPGA load fail
D=CnC FPGA load fail
E=VersaFEC FPGA load fail
F=Calibration data missing
Exception – 600L: F=Rx synthesizer2
G=Reference unlocked (Note: Tx off)
H=TXDCM fail
I=Over Temperature Alarm
J=Packet Processor mailbox fault
K=Fractional CnC use only
L=Top Card 3.6 Volt fault
M=Top Card 5.5 Volt fault
N=Calibration data transfer error
P=VersaFEC-2 FPGA load fail
b=Tx Traffic status:
0=Tx traffic OK
1=No clock from terrestrial interface
2=Tx FIFO slip
3=AIS detected on incoming data
4=AUPC upper limit reached
5=(Hi-Stab) No External Ref found (no activity)
6=BUC summary alarm (if ABA enabled)
7=G.703 Loss of Signal (only valid in Clock Extend Mode)
N/A
FLT?
FLT=abcdefghxx
(see Description of
Arguments)
Exception –
600L Emulation format:
FLT=abcdef
