CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–55
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
…Faults and
Status (cont.)
Exceptions – 600L: 6=BUC current
7=BUC voltage
8=BUC no comms/bad checksum
9=BUC PLL
A=BUC temperature
8=CnC-APC home state
9=PMSI Sym Clock Fail
c=Rx Traffic status:
0=Rx Traffic OK
1=Demodulator unlocked
2=AGC Alarm - signal out of range
3=Demux Lock (Frame SYNC)
4=CnC Lock
5=Buffer Slip
6=AIS detected on incoming data
7=Eb/No alarm
8=Buffer Clock activity
9=LNB summary alarm (if ALA enabled)
A=QDI Deframer Unlocked
Exception – 600L: 9=LNB current
A=LNB voltage
B,C,D,E,F=Spare
G=CnC-APC band mismatch
d=Open Network:
0=No Faults
1=Loss of Tx frame
2=BER Alarm
3=Loss of Tx multiframe
4=Tx signaling AIS
5=Tx Remote alarm
6=IBS satellite alarm
7=IDR Rx BWA1
8=IDR Rx BWA2
9=IDR Rx BWA3
A=IDR Rx BWA4
B=IDR Tx BWA1
C=IDR Tx BWA2
D=IDR Tx BWA3
E=IDR Tx BWA4
e=Change in modem fault status since last poll
0=unchanged
1=changed
f=Change in modem configuration since last poll
0=unchanged
1=changed
g=BUC status/faults:
0=OK, masked, or not present
1=BUC current
2=BUC voltage
3=spare
