CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–63
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
WAN Buffer
Length
WBL=
3 bytes
Command or Query.
Sets or returns WAN Buffer Length in the form xxx, where:
xxx=Value, in 20 millisecond steps, from 020 thru 780.
EXAMPLE: <0/WBL=100
WBL=
WBL?
WBL*
WBL#
WBL?
WBL=xxx
(see Description of
Arguments)
Average WAN
Buffer Fill State
N/A
2 bytes,
numeric
Query only.
Returns the value of Average WAN buffer fill state in the form xx, where:
xx=percentage value, from 00 thru 99(%).
EXAMPLE: <0/WBF? >0000/WBF=33 (indicates fill state at 33%)
N/A
WBF?
WBF=xx
(see Description
of Arguments)
Switch MAC
Learning
SML=
1byte, 0 or 1
Command or Query.
Sets or returns Switch MAC learning in the form x, where:
0=Off
1 =On
SML=
SML?
SML*
SML#
SML?
SML=x
(see Description of
Arguments)
VLAN Mode
Enable
SVM=
1 byte, 0 or 1
Command or Query.
Sets or returns VLAN Mode in the form x, where:
0=VLAN is Disabled
1=VLAN is Enabled
SVM=
SVM?
SVM*
SVM#
SVM?
SVM=x
(see Description of
Arguments)
VLAN Table
SVT=
Up to 287 byes
Command or Query.
Sets or returns all entries in the VLAN table in the form aaaabcde,aaaabcde,aaaabcde,…, where:
aaaa=VLAN ID: Value range=0001-4095, must not be duplicate of any PVID.
b=property of port 1: 0=Tagged, 1=Filtered, 2=Untagged
c=property of port 2: 0=Tagged, 1=Filtered, 2=Untagged
d=property of port 3: 0=Tagged, 1=Filtered, 2=Untagged
e=property of port 4: 0=Tagged, 1=Filtered, 2=Untagged
SVT=
SVT?
SVT*
SVT#
SVT?
SVT=aaaabcde,aaaab
cde,aaaabcde…
(see Description of
Arguments)
Add entry to
VLAN table
SVA=
8 bytes
Command only.
Adds entry to VLAN table in the form aaaabcde, where:
aaaa=New VLAN ID: Value range=0001-4095, must not be duplicate of any PVID or VLAN ID existing in VLAN table.
b=property of port 1: 0=Tagged, 1=Filtered, 2=Untagged
c=property of port 2: 0=Tagged, 1=Filtered, 2=Untagged
d=property of port 3: 0=Tagged, 1=Filtered, 2=Untagged
e=property of port 4: 0=Tagged, 1=Filtered, 2=Untagged
SVA=
SVA?
SVA*
SVA#
N/A
SVA=aaaabcde
(see Description of
Arguments)
Management
VLAN ID
SMV=
4 bytes,
numeric
Command or Query.
Sets or returns the Management Port’s VLAN ID in the form aaaa, where:
aaaa=the VLAN ID number in the range 0001-4095.
SMV=
SMV?
SMV*
SMV#
SMV?
SMV=aaaa
(see Description of
Arguments)
Delete entry in
VLAN table
SVD=
4 bytes,
numeric
Command only.
Deletes VLAN table entry in the form aaaa, where:
aaaa=the VLAN ID number in the range 0001-4095.
SVD=
SVD?
SVD*
SVD#
N/A
SVD=aaaa
(see Description of
Arguments)
