CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–64
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
Packet
Processor Card
Enable
PPE=
1 byte, 0 or 1
Command or Query.
Sets or returns Packet Processor Card operation in the form x, where:
0=Packet Processor Card is Disabled
1=Packet Processor Card is Enabled
NOTE: Change of this configuration results in modem auto-reboot only when IP Packet Processor option card is installed
and enabled. Otherwise, when the IP Packet Processor option card is not installed, this selection is stored but is otherwise
non-functional.
PPE=
PPE?
PPE*
PPE#
PPE?
PPE=x
(see Description of
Arguments)
QoS Mode
QOS=
2 bytes, each 0
thru 3
Command or Query.
Sets or returns QoS (Quality of Service) Mode in the form ab, where:
a=Layer 2 QoS:
0=Off, Layer 2 QoS is disabled
1=VLAN Priority only
2=Port Priority only
3=VLAN and Port Priority
b =Layer 3 QoS:
0=Off, Layer 3 QoS is disabled
1=Advanced QoS Max / Priority (requires Advanced QoS FAST Option)*
2=Advanced QoS Min Max (requires Advanced QoS FAST Option)*
3=Advanced QoS DiffServ (requires Advanced QoS FAST Option)*
*NOTE: Layer 3 QoS settings 1 through 3 apply to modem only with IP Packet Processor option card installed and
enabled.
QOS=
QOS?
QOS*
QOS#
QOS?
QOS=ab
(see Description of
Arguments)
Switch Ports
Configuration
SPC=
47 bytes
Command or Query.
Sets or returns Ethernet switch ports’ priority and PVID in the form 1abccccdxxx;2abccccdxxx;3abccccdxxx;4abccccdxxx,
where:
1, 2, 3, or 4=Port number.
a=Port priority: Value=1, 2, 3 or 4 (the higher the number, the higher the priority).
b=Port Native Mode: 0=Native Mode Disabled, 1=Native Mode Enabled.
cccc=Port VLAN ID: Value range=0000-4095 – Value 0000 is only valid when port Native Mode is disabled.
d=Pause flow control. 0=Off, 1=On
xxx=Reserved.
SPC=
SPC?
SPC*
SPC#
SPC?
SPC=1abccccdxxx,2ab
ccccdxxx,3abccccdxxx,
4abccccdxxx
(see Description of
Arguments)
Edit entry in
VLAN table
SVE=
8 bytes
Command only.
Edit VLAN table entry in the form aaaabcde, where:
aaaa=existing VLAN ID – Value range is 0001-4095.
b=property of port 1: 0=Tagged, 1=Filtered, 2=Untagged
c=property of port 2: 0=Tagged, 1=Filtered, 2=Untagged
d=property of port 3: 0=Tagged, 1=Filtered, 2=Untagged
e=property of port 4: 0=Tagged, 1=Filtered, 2=Untagged
SVE=
SVE?
SVE*
SVE#
N/A
SVE=aaaabcde
(see Description of
Arguments)
Packet
Processor
Working Mode
WMD=
1 byte, 0 thru 3
Command or Query.
Sets or returns Packet Processor Working Mode in the form x, where:
0=Managed Switch
1=Router Point to Point*
2=Router Multipoint Hub*
3=Router Multipoint Remote*
*NOTE: Settings 1 through 3 apply to modem only with IP Packet Processor option card installed and enabled.
WMD=
WMD?
WMD*
WMD#
WMD?
WMD=x
(see Description of
Arguments)
