Comtech EF Data CDM-625A - Page 379

CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–65
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
Dedicated
Management
Port
DMP=
1 byte, 0 thru 8
Command or Query.
Sets or returns Dedicated Ethernet Management port in Redundancy system in the form x, where:
0=Disabled (Any Ethernet port can do management, default value)
1=Port 1
2=Port 2
3=Port 3
4=Port 4
5=Port 1 – Local only*
6=Port 2 – Local only*
7=Port 3 – Local only*
8=Port 4 – Local only*
NOTES:
1) VLAN must be Disabled to be able to select a port as Dedicated Management Port.
2) * Only LAN devices can access M&C of modem. NO remote modem access.
DMP=
DMP?
DMP*
DMP#
DMP?
DMP=x
(see Description of
Arguments)
Ethernet 2048
Frame Size
EFS=
1 byte, 0 or 1
Command or Query.
Sets or returns 2048-byte Ethernet Frame Size function in the form x, where:
0=2048 Ethernet Frame Size is Disabled
1=2048 Ethernet Frame Size is Enabled (supported by modem with baseboard hardware Rev2 and above)
EFS=
EFS?
EFS*
EFS#
EFS?
EFS=x
(see Description of
Arguments)
Host Access List
Enable/Disable
ACL=
1 byte, 0 or 1
Command or Query.
Sets or returns IP Host Access List function in the form x, where:
0=Host Access List is Disabled
1=Host Access List is Enabled
ACL=
ACL?
ACL*
ACL#
ACL?
ACL=x
(see Description of
Arguments)
Packet
Processor
Redundancy
PRD=
1 byte, 0 or 1
Command or Query.
Valid only when Packet Processor is installed and Enabled.
Sets or returns Packet Processor Redundancy function in the form x, where:
0=Disable Packet Processor Redundancy
1=Enable Packet Processor Redundancy
PRD=
PRD?
PRD*
PRD#
PRD?
PRD=x
(see Description of
Arguments)
Precision Time
Protocol
PTP=
1 byte, 0 or 1
Command or Query.
Sets or returns Precision Time Protocol Feature function in the form x, where:
0=PTP is Disabled
1=PTP Enabled
PTP=
PTP?
PTP*
PTP#
PTP?
PTP=x
(see Description of
Arguments)
Precision Time
Protocol
Grandmaster
PTM=
1 byte, 0 or 1
Command or Query.
Sets or returns Precision Time Protocol Grandmaster function in the form x, where:
0=Grandmaster reachable over LAN.
1=Grandmaster reachable over WAN.
PTM=
PTM?
PTM*
PTM#
PTM?
PTM=x
(see Description of
Arguments)
Packet
Processor
Bootrom FW
Version
N/A
None
Query only.
Valid only when Packet Processor is installed and Enabled.
Returns Packet Processor Bootrom firmware version.
N/A
VS0?
VS0=x
x is variable length of
text
Packet
Processor
Image1 FW
Version
N/A
None
Query only.
Valid only when Packet Processor is installed and Enabled.
Returns Packet Processor Image 1 firmware version.
N/A
VS1?
VS1=x
x is variable length of
text
