CDM-625A Advanced Satellite Modem MN-CDM625A
Telnet Command Line Interface (CLI) Operation Revision 4
9–57
9.3.5.1 Home > WAN > QoS Submenu
Open the QoS (Quality of Service) submenu from the WAN submenu. The appearance of this
page changes with the selected Advanced QoS mode (see Sect. 9.3.4.2 Home > Network > LAN
IP).
With Advanced QoS mode set to Max-Priority or Min-Max:
With Advanced QoS mode set to DiffServ:
This submenu contains the following options:
Hot
Key
Page / Dialog Window Description / Option Entry
A
QoS Max-Pri / Min-Max Table
(visible only when Advanced QoS
mode is set to Max-Priority or Min-
Max)
See Sect. 0
B
QoS Differentiated Services Table
(visible only when QoS mode is set to
Differentiated Services)
See Sect. 9.3.5.1.2
C
QoS SAR Feature
Use the ↑↓ arrow keys to select Disable or Enable
D
Delete All Max-Pri / Min-Max rules
Use the ↑↓ arrow keys to select No or Yes
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Network
submenu.
