CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–25
P-Supplies: 7V:OK 17V:OK
-7V:OK 12V:OK (EC)
Down-Converter: Comms:OK L-Synth:OK
Over-Temp:OK Ku-Synth:OK
HPA: Comms:OK 9.75V:OK
Over-Temp:OK Bias:OK -5V:OK
Once any KST Alarms screen has been viewed, press ENTER or CLEAR to return to the previous
menu.
10.3.3.3.3.4 ODU: FSK-control BUC
The menus that follow assume that you have selected and the system has identified a
BUC connected via the Tx IF port.
BUC controls via FSK:
Configuration Status Advanced-FSK ()
Use the
◄ ►arrow keys to select Configuration, Status, or Advanced-FSK, and then press ENTER.
10.3.3.3.3.4.1 ODU: FSK-control BUC Configuration
BUC: Tx:On (Off,On)
Addr:01 (1-15) ()
Use the
◄ ►arrow keys to select Tx: or Addr:
On the top line – For Tx: use the
▲▼ arrow keys to select Off or On.
On the bottom line – For Addr: use the
▲▼ arrow keys to select an address from 01 to 15.
Press ENTER when done.
10.3.3.3.3.4.2 ODU: FSK-control BUC Status
BUC: Pwr=16.2dBm=00.0W Pclass=5 W
PLL=locked +045°C Sw-Ver=01
This screen provides read-only status information for the BUC setup.
