CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–26
Press ENTER or CLEAR to return to the previous menu.
10.3.3.3.3.4.3 ODU: FSK-control  BUC  Advanced-FSK
Advanced FSK:
CEFD BUC Type: LPOD (LPOD,2LPODs) ()
Use the ▲▼arrow keys to select LPOD or 2LPODs, and then press ENTER.
10.3.3.3.3.4.3.1 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD)
LPOD S/N: 123456789
Cnfg Monitor Alarms Stats Info Redun ()
This submenu and its nested menus are identical in form and function for the
following menu structures:
ODU: FSK-control

Advanced-FSK

LPOD

ODU: FSK-control

Advanced-FSK

2LPODs

Online LPOD

ODU: FSK-control

Advanced-FSK

2LPODs

Offline LPOD

Use the
◄ ►arrow keys to select Cnfg, Monitor, Alarms, Stats, Info, or Redun, and then press
ENTER.
10.3.3.3.3.4.3.1.1 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD)  Cnfg
Configuration settings:
Amplifier LNB Mask Misc ()
Use the
◄ ►arrow keys to select Amplifier, LNB, Mask, or Misc, and then press ENTER.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Cnfg  Amplifier
Amplifier: Att=10.00 dB Amp=On
Mute=Disabled Att-Offset=00.00 dB ()
Use the
◄ ►arrow keys to select a setting, and then use the ▲▼ arrow keys to change that
setting:
