CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–33
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Amp
Amp Info: Att=20.00dB Amp=On
Mute=Disabled Att-Offset=00.00dB
This screen displays the RF Amplifier state, RF Mute state, Attenuation, and AUX Mute state.
ODU: FSK-control BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  LNB
LNB Current: Src=On SwitchBiasTee=Off
Window:30% Alarm=Disabled
This screen displays the LNB Current information.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Mask
Mask: LFRFPwr=Masked ERLD=Masked
FanSpd=Alarm LNBCD=Alarm LNB22V=Alarm
This screen displays the LPOD mask settings.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Misc
Misc: AFR=Enabled Ref-Adjust=087
LowFwdPowerThreshold=00.00
This screen displays the Auto Fault Recovery state, the Internal 10MHz Reference setting, and
the Low Forward Power Threshold setting.
