CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–34
10.3.3.3.3.4.3.1.6 ODU: FSK-control BUC Advanced-FSK LPOD
(2LPODs
Online/Offline LPOD) Redun
Redundancy-Switch-Mode=1:1 Red TX+RX
Force-Online=N Online-State=Offline()
Use the
◄ ►arrow keys to select a setting, and then use the ▲▼ arrow keys to change that
setting:
Selection Setting
Redundancy-Switch-Mode Off, 1:1 Red Tx, 1:1 Red TX+RX, Manual.
Force-Online
Select Yes to force Offline unit to generate a redundant switchover.
Otherwise, select No.
Online-State Read-only. Displays status as Online or Offline.
Press ENTER when done.
ODU: FSK-control BUC Advanced-FSK 2LPODs
The menus that follow assume that you have selected, and the system has
identified, two LPODs connected via the Tx IF port.
1:1 Monitor & Control
Online LPOD Offline LPOD ()
Use the
◄ ►arrow keys to select Online LPOD or Offline LPOD, and then press ENTER.
ODU: FSK-control BUC Advanced-FSK 2LPODs Online
LPOD
ODU: FSK-control BUC Advanced-FSK 2LPODs Offline
LPOD
LPOD S/N: 123456789
Cnfg Monitor Alarms Stats Info Redun ()
Use the
◄ ►arrow keys to select Cnfg, Monitor, Alarms, Stats, Info, or Redun, and then press
ENTER.
Sect. 10.3.3.3.3.4.3.1 ODU: FSK-control
BUC
Advanced-FSK
LPOD for
complete information for these nested menu choices.
