CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–58
10.5.1.2.1.3 Home > Outdoor Unit (ODU) > CSAT-5060 > Unit Settings 1/2,
2/2
Open the Unit Settings 1/2 page or the Unit Settings 2/2 page from the nested CSAT-5060
submenu.
The Unit Settings 1/2 page contains the following options:
Hot
Key
Dialog Window Option Entry
A Unit Mute Mode
Use the ↑↓ arrow keys to select Unmuted After Freq Change or
Muted After Freq Change
B
Unit Auto Fault Recovery
Use the ↑↓ arrow keys to select Disabled or Enabled
C
Unit Cold Start Use the
↑↓
arrow keys to select
Disabled
or
Enabled
The Unit Settings 2/2 page contains the following options:
Hot
Key
Dialog Window Option Entry
A Unit Ext Ref Fault Logic Use the ↑↓ arrow keys to select No Summary or Summary
B Unit Ref Osc Adjust Enter a value from 0 to 255
C Circuit ID Enter an identifying label for the ODU here
Typical for either page, press a hot key to open a dialog window. Otherwise, press [ESC] to
return to the nested CSAT-5060 submenu.
