CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–59
10.5.1.2.1.4 Home > Outdoor Unit (ODU) > CSAT-5060 > LNA Settings
Open the LNA Settings page from the nested CSAT-5060 submenu. This page contains the
following options:
Hot
Key
Dialog Window Option Entry
A Unit LNA Current Window
Enter a value as follows:
• Range 1 – 20 to 50
•
Range 2 – 99 to 99
B Unit LNA Current Window
Use the ↑↓ arrow keys to select Disabled, Enabled, or Enabled
When Online
C Unit LNA Fault Logic Use the ↑↓ arrow keys to select No Summary or Summary
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested CSAT-
5060 submenu.
