CDM-625A Advanced Satellite Modem MN-CDM625A
Introduction Revision 4
1–28
ESC++ (NO REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
No FEC, BPSK
64.0
12304.6
No FEC, O/QPSK
64.0
24609.3
VITERBI, BPSK, 1/2
64.0
5921.0
VITERBI, O/QPSK, 1/2
64.0
12304.6
VITERBI, O/QPSK, 3/4
64.0
18457.0
VITERBI, O/QPSK, 7/8
64.0
21533.2
SEQUENTIAL, BPSK, 1/2
64.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
64.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
64.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
64.0
2048.0
TRELLIS, 8PSK, 2/3
64.0
24609.3
TPC, BPSK, 5/16
64.0
3700.6
TPC, BPSK, 21/44 (aka 1/2)
64.0
5651.9
TPC, O/QPSK, 21/44 (aka 1/2)
64.0
11745.3
TPC, O/QPSK, 3/4
64.0
18457.0
TPC, O/QPSK, 17/18 (aka 0.95)
64.0
23242.1
TPC, O/QPSK, 7/8
64.0
21533.2
TPC, 8PSK/8-QAM, 3/4
64.0
24609.3
TPC, 8PSK/8-QAM 17/18 (aka 0.95)
64.0
24609.3
TPC, 8PSK/8-QAM, 7/8
64.0
24609.3
TPC, 16-QAM, 3/4
64.0
24609.3
TPC, 16-QAM, 7/8
64.0
24609.3
LDPC, BPSK, 1/2
64.0
5921.0
LDPC, O/QPSK, 1/2
64.0
12304.6
LDPC, O/QPSK, 3/4
64.0
18457.0
LDPC, O/QPSK, 2/3
64.0
16406.2
LDPC, 8PSK/8-QAM, 3/4
64.0
24609.3
LDPC, 8PSK/8-QAM,2/3
64.0
24609.3
LDPC, 16-QAM, 3/4
64.0
24609.3
ESC++ (ANY REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
VITERBI, BPSK, 1/2
64.0
5263.1
VITERBI, O/QPSK, 1/2
64.0
10937.5
VITERBI, O/QPSK, 3/4
64.0
16406.2
VITERBI, O/QPSK, 7/8
64.0
19140.6
SEQUENTIAL, BPSK, 1/2
64.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
64.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
64.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
64.0
2048.0
TRELLIS, 8PSK, 2/3
64.0
21875.0
VITERBI, 16-QAM, 3/4
64.0
21875.0
VITERBI, 16-QAM, 7/8
64.0
21875.0
