CDM-625A Advanced Satellite Modem MN-CDM625A
Introduction Revision 4
1–29
VersaFEC (ANY MODE)
Lower Limit (kbps)
Upper Limit (kbps)
VersaFEC BPSK Rate 0.488
18.0
5700.0
VersaFEC QPSK Rate 0.533
20.0
10000.0
VersaFEC QPSK Rate 0.631
23.0
10000.0
VersaFEC QPSK Rate 0.706
26.0
10000.0
VersaFEC QPSK Rate 0.803
28.0
12000.0
VersaFEC 8-QAM Rate 0.576 (ECCM)
32.0
11000.0
VersaFEC 8-QAM Rate 0.642
35.0
12000.0
VersaFEC 8-QAM Rate 0.711
39.0
12000.0
VersaFEC 8-QAM Rate 0.780
43.0
12000.0
VersaFEC 16-QAM Rate 0.644 (ECCM)
47.0
11000.0
VersaFEC 16-QAM Rate 0.731
53.0
12000.0
VersaFEC 16-QAM Rate 0.780
57.0
14000.0
VersaFEC 16-QAM Rate 0.829
60.0
14000.0
VersaFEC 16-QAM Rate 0.853
62.0
16000.0
ULL BPSK Rate 0.493
18.0
5700.0
ULL QPSK Rate 0.493
18.0
6000.0
ULL QPSK Rate 0.654
24.0
9000.0
ULL QPSK Rate 0.734
27.0
9000.0
VersaFEC Adaptive Coding and Modulation (ACM): See Sect. 1.4.8.1 Specifications
VersaFEC-2 Adaptive Coding and Modulation (ACM): See Sect. 1.4.8.2 Specifications
