Unidrive SP Advanced User Guide 265
Issue Number: 7 www.controltechniques.com
Table 5-9
Figure 5-31 SM-I/O Plus Analog Input/Output logic diagram
The module has two analog inputs (AI1 and AI2) and one analog output (AO1). The inputs operate in voltage mode only and the nominal full scale
level in voltage mode is 9.8V. This ensures that when the input is driven from a voltage produced from the drive’s own 10V supply, the input can reach
full scale. The output operates in voltage mode only.
Terminal and Type
I/O state Invert
Source/
destination
Output select
Parameter Parameter Default Parameter Default Parameter Default
T2 input / output 1 Pr x.09 Pr x.11 0Pr x.21 00.00 Pr x.31 0
T3 input / output 2 Pr x.10 Pr x.12 0Pr x.22 00.00 Pr x.32 0
T4 input / output 3 Pr x.03 Pr x.13 0Pr x.23 00.00 Pr x.33 0
T6 input 4 Pr x.04 Pr x.14 0Pr x.24 00.00
T7 Input 5 Pr x.05 Pr x.15 0Pr x.25 00.00
T8 Input 6 Pr x.06 Pr x.16 0Pr x.26 00.00
T21 Relay 7 Pr x.07 Pr x.17 0Pr x.27 00.00
T23 Relay 8 Pr x.08 Pr x.18 0Pr x.28 00.00
X.41
T9 Analog
input 4
scaling
??.??
Any
unprotected
variable
parameter
??.??
X.43
T9 Analog
input 4
destination
x(-1)
X.42
T9 Analog input
4 invert
X.40
T9 Analog input 4
0.XX
0.XX
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default settings
X.45
??.??
Any
unprotected
variable
parameter
??.??
X.47
x(-1)
X
.46
X.44
T10 Analog input
5
invert
T9 Analog input 4
T10 Analog input 5
T10 Analog input 5
T10 Analog
input 5
destination
T10 Analog
input 5
scaling
