These parameters are the general setup parameters for the CTNet port. The baud rate strings are defined as follows:
x.25 CTNet sync setup ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0,000 to 9,999
Update Rate Not Applicable
Display Value Description
5.000 0 5Mbit/s
2.500 1 2.5Mbit/s (default)
1.250 2 1.25Mbit/s
0.625 3 625kbit/s
x.26 CTNet easy mode - first cyclic parameter destination node ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 25,503
Update Rate Not Applicable
x.27 CTNet easy mode - first cyclic source parameter ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 9,999
Update Rate Not Applicable
x.28 CTNet easy mode - second cyclic parameter destination node ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 25,503
Update Rate Not Applicable
x.29 CTNet easy mode - second cyclic source parameter ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 9,999
Update Rate Not Applicable
