Control Techniques unidrive sp User Manual

Menus 15 to 17
SM-Applicat’ns
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
294 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
These three bit parameters control the non-volatile save and restore features of the application module. The non-volatile PLC register sets and menu
20 parameter data can be saved in the application module flash memory (note: only one application module out of the possible maximum of three
slots should be used to save and restore menu 20 otherwise the behaviour is undefined). Data can be saved on request by setting the save request
bit (the module will clear this bit once the data has been saved).
The DPL program is stopped during the save sequence and a warm restart generated once the save is over. If the power down enable bit is set then
data is saved automatically when a UU trip is detected.
This parameter is not cached i.e. the current value will be used at the next power down.
This parameter allows the user to specify the identity of the CTNet token ring to which a SM-Applications is connected. In a system incorporating a
single token ring this parameter can be left at its default value. In a system incorporating multiple token rings, separate IDs should be set for each ring
- the combination of CTNET Token Ring ID and CTNet node address should be unique.
x.21 Enable menu 20 save and restore
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default All drives 0
Update Rate Not Applicable
x.22 CTNet token ring ID ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 255
Update Rate Not Applicable
x.23 CTNet node address ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 255
Update Rate Not Applicable
x.24 CTNet baud rate ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default All drives 1
Range All drives 0 to 3
Update Rate Not Applicable
NOTE
