The above parameters are the CTNet Easy Mode set-up parameters. Pr x.26 to Pr x.31 allow 3 parameters to be setup for cyclic transmission to
remote nodes via CTNet. Pr x.32 to Pr x.34 allow the user to specify which parameters should be updated from cyclic data received in slots 1 to 3 on
the local node.
x.30 CTNet easy mode - third cyclic parameter destination node ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 25,503
Update Rate Not Applicable
x.31 CTNet easy mode - third cyclic source parameter ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 9,999
Update Rate Not Applicable
x.32 CTNet easy mode set-up - transfer slot 1 destination parameter ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0,000 to 9,999
Update Rate Not Applicable
x.33 CTNet easy mode set-up - transfer slot 2 destination parameter♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0,000 to 9,999
Update Rate Not Applicable
x.34 CTNet easy mode set-up - transfer slot 3 destination parameter ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0,000 to 9,999
Update Rate Not Applicable
