Dell S4048T User Manual

VRF supports route redistribution between routing protocols (including static routes) only when the routes are
within the same VRF.
Dell Networking OS uses both the VRF name and VRF ID to manage VRF instances. The VRF name and VRF ID
number are assigned using the ip vrf command. The VRF ID is displayed in show ip vrf command output.
The VRF ID is not exchanged between routers. VRF IDs are local to a router.
VRF supports some routing protocols only on the default VRF (default-vrf) instance. Table 1 displays the
software features supported in VRF and whether they are supported on all VRF instances or only the default
VRF.
Table 97. Software Features Supported on VRF
Feature/Capability Support Status for Default VRF Support Status for Non-default
VRF
Configuration rollback for
commands introduced or
modified
Yes No
LLDP protocol on the port Yes No
802.1x protocol on the VLAN port Yes No
OSPF, RIP, ISIS, BGP on physical
and logical interfaces
Yes Yes
NOTE: OSPF supported on
all VRF ports. OSPF V2 and
BGP V4 are supported on
non-default-VRF ports also.
Others supported only on
default-VRF ports.
Dynamic Port-channel (LACP) on
VLAN port or a Layer 3 port
Yes Yes
Static Port-channel as VLAN port
or a Layer 3 port
Yes Yes
Port-monitoring Yes No
BFD on physical and logical
interfaces
Yes No
PVST, MSTP, RSTP and 802.1D STP
for VLANs
Yes No
FRRP (if applicable) for VLANs Yes No
Multicast protocols (PIM-SM,
MSDP)
Yes Yes
PIM-DM No No
Layer 3 (IPv4/IPv6) ACLs,
TraceLists, PBR, QoS on VLANs
Yes Yes
Virtual Routing and Forwarding (VRF) 1188

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
