Connectrix DS-32M2 User Guide
Product Manager Overview
In the Hardware view, color-coded indicators reflect the status of
actual LEDs on the switch FRUs. The status indicator at the lower left
displays a symbol to represent the most degraded status currently
reported by any of the switch FRUs. For example, for a port failure,
indicated by a red and yellow diamond on a port, a yellow triangle
appears on the alert panel to indicate a degraded condition.
For an explanation of the various alert symbols, refer to Table 4-1 on
page 4-5.
Displaying Properties
and Options
Double-clicking anywhere on the switch except on a FRU displays a
Switch Properties window. Double-clicking on the power supply or
cooling fan module displays a FRU Properties window containing
detailed information on the hardware component.
Right-clicking anywhere on the switch except on a FRU displays a list
of options for the switch. Refer to Using Menu Options on page 4-13
for more information.
For reference, here are the menu options:
â—† Switch Properties
â—† Enable Unit Beaconing
â—† Clear System Error Light
â—† IPL Switch
â—† Set Switch Date and Time
â—† Set Switch Online State
Node List View
Clicking the Node List tab on the Product Manager window (refer to
Figure 3-7 on page 3-17) displays a table of information about all
node attachments or N_Ports that have logged into existing F_Ports
on the switch. Only N_Ports appear in the Node List view after nodes
have logged in to the fabric.
The columns that appear in the table include:
â—† Port number where the node is attached
â—† (S/390 mode only) Port address
â—† Node type
â—† WWN of the attached node (device)
â—† BB_Credit value used by the attached node
