Fibre Channel Fabric Element MIB Support
A-17
Using SNMP to Manage the Switch
Operation: Fabric
Login Table
The Fcflogintable contains the service parameters for each F_Port
in the fabric element that have been established from the most recent
fabric login (implicit or explicit).
Table A-7 Operation: Fabric Login
Variable Description
fcFxlogiModuleIndex This object identifies the module containing the F_Port for which this entry contains
information. This number ranges from 1 to AS_glob.prod_cnfg_ptr->max_nbr_modules.
fcFxlogiFxPortIndex This object identifies the F_Port within the module. This number ranges from 1 to the
value of fcFeModulePortCapacity for the associated module. The value remains constant
for the identified F_Port until the module is re-initialized. This number ranges from 1 to
AS_glob.prod_cnfg_ptr->ports_per_module.
fcFxlogiNxPortIndex The object identifies the associated NxPort in the attachment for which the entry contains
information.
fcFxPortFcphVersionAgreed The version of FC-PH that the F_Port has agreed to support from the Fabric Login.
fcFxPortNxPortBbCredit The total number of buffers available for holding Class 1 connect-request, Class 2 or
Class 3 frames to be transmitted to the attached NxPort. It is for buffer- to-buffer flow
control in the direction from F_Port to NxPort. The buffer-to-buffer flow control mechanism
is indicated in the respective fcF_PortBbCreditModel.
fcFxPortNxPortRxDataFieldSize The Receive Data Field Size of the attached NxPort. This is a binary value that specifies
the largest Data Field Size for an FT_1 frame that can be received by the NxPort. The
value is in number of bytes and ranges from 128 to 2112 inclusive.
fcFxPortCosSuppAgreed A variable indicating that the attached NxPort has requested the F_Port for the support of
classes of services and the F_Port has granted the request.
fcFxPortIntermixSuppAgreed A variable indicating that the attached NxPort has requested the F_Port for the support of
Intermix and the F_Port has granted the request. This flag is only valid if Class 1 service is
supported. The values are defined as follow: yes(1) and no(2). This is always no(2).
fcFxPortStackedConnModeAgreed A variable indicating whether the F_Port has agreed to support stacked connect from the
Fabric Login. This is only meaningful if Class 1 service has been agreed. This is always
none(1).
fcFxPortClass2SeqDelivAgreed A variable indicating whether the F_Port has agreed to support Class 2 sequential delivery
from the Fabric Login. This is only meaningful if Class 2 service has been agreed. The
values are defined as follow: yes(1) and no(2).
fcFxPortClass3SeqDelivAgreed A flag indicating whether the F_Port has agreed to support Class 3 sequential delivery
from the Fabric Login. This is only meaningful if Class 3 service has been agreed. The
values are defined as follow: yes(1) and no(2).
