Using the Port List View
4-21
Monitoring and Managing the Switch
Using the Port List View
To display the Port List view (Figure 4-5), select the Product Manager
Port List tab.
Figure 4-5 Port List View
The Port List view displays the following information on all ports
that can be installed in the switch. All information is updated
automatically.
◆ # — Port number: 0 through 31.
◆ Addr (S/390 mode only) — Displays the logical address of the
port. The address equals the port number, plus 4. For example,
the address for port 0 is 4 (0+4). If port addresses have been
swapped, those addresses will be followed by an asterisk (*).
◆ Name — Port name as configured through the Configure Ports
dialog box.
