6
Using Logs
6-3
Using Logs
To save a log file in ASCII format to a location on your system’s
hard drive or to a diskette, use the following steps. You can open
this file in any desktop publisher for viewing or printing.
a. Click Export on the log window.
b. In the Save dialog box, select the folder where you want to
save the file.
c. Type in a file name and extension into the File name field.
d. Click Save. The file is saved to the specified folder as an ASCII
text file.
Expanding Columns
You can expand columns in logs as follows:
1. Move over the line separating two column headings until a
double arrow appears.
2. Hold down the left mouse button and widen the column as
necessary.
Sorting Entries
Sort log entries in columns by clicking a column heading. A Down
arrow in the header indicates sorting in descending order. An Up
arrow indicates sorting in ascending order. Click once to sort. Click
again to reverse the sort.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the EMC Connectrix DS-32M2 and is the answer not in the manual?

EMC Connectrix DS-32M2 Specifications

General IconGeneral
ModelConnectrix DS-32M2
TypeFiber Channel Switch
Ports32
Hot-swappableYes
Port Speed2 Gbps
ManagementWeb Tools, Command Line Interface (CLI), SNMP
Power SupplyDual redundant power supplies
Data Transfer Rate2 Gbps
Fabric OSFabric OS
