Fibre Channel Fabric Element MIB Support
A-15
Using SNMP to Manage the Switch
Operation: F_Port
Operation Table
The Fcfportopertable contains the operational status and parameters
of the F_Ports.
Table A-5 F_Port Operation Table
Variable Description
fcFxPortOperModuleIndex This object identifies the module containing the F_Port for which this entry contains
information. This number ranges from 1 to AS_glob.prod_cnfg_ptr->max_nbr_modules.
fcFxPortOperFxPortIndex This object identifies the F_Port within the module. This number ranges from 1 to the value
of fcFeModulePortCapacity for the associated module. The value remains constant for the
identified F_Port until the module is re-initialized. This number ranges from 1 to
AS_glob.prod_cnfg_ptr->ports_per_module.
fcFxPortID The address identifier by which this F_Port is identified within the Fabric. The F_Port may
assign its address identifier to its attached NxPort(s) during Fabric Login. Return a port id if
the port is login into the fabric, otherwise this address is 000000 in Fuji 1.0.
fcFPortAttachedPortName The port name of the attached N_Port, if applicable. If the value of this object is
’0000000000000000’H, this F_Port has no NxPort attached to it. This variable has been
deprecated and may be implemented for backward compability.
fcFPortConnectedPort The address identifier of the destination F_Port with which this F_Port is currently engaged
in a either a Class 1 or loop connection. If the value of this object is ’000000’H, this F_Port
is not engaged in a class 1 connection. This variable has been deprecated and may be
implemented for backward compability. This address is fixed at 0x000000.
fcFxPortBbCreditAvailable The number of buffers currently available for receiving frames from the attached port in the
buffer-to-buffer flow control. The value should be less than or equal to fcF_PortBbCredit.
fcFxPortOperMode The current operational mode of the F_Port.
This value is fport(2) if the port_state_data is unavailable or the port is a fport, or
unknown(1) for the other port state.
fcFxPortAdminMode The desired operational mode of the F_Port.
This value is fport(2) if the port_state_data is unavailable or the port is a fport, or
unknown(1) for the other port state.
